آی سی هارد سن دیسک KLMAG4FEJA-A003

مشخصات آی سی KLMAG4FEJA-A003 :

توضیحات فنی آی سی KLMAG4FEJA-A003 :

HiPower mode is OFF

Frequence: 14 Mhz

CMD Pullup Level: 3227 mV

CMD Active Level: 3289 mV

EMMC Device Information :

EMMC CID: 1501004D41473446411963E00354CE9C

EMMC CSD: D02701320F5903FFF6DBFFEF8A404066

EMMC Manufacture Name: SAMSUNG

EMMC Manufacture ID: 0x15 , OEM ID: 0100

EMMC Manufacture Date: 12/2011 , Rev: 19

EMMC NAME: MAG4FA , S/N: 63E00354 , rev. 19

EMMC NAME (HEX): 4D4147344641

EMMC ROM 1 (Main User Data) Capacity: 15028 MB (0003AB400000)

EMMC ROM 2/3 (Boot Partition 1/2) Capacity: 512 KB (000000080000)

EMMC RPMB (Replay Protected Memory Block) Capacity: 128 KB (000000020000)

EMMC Permanent Write Protection: No

EMMC Temporary Write Protection: No

Extended CSD Information :

Extended CSD rev: 1.5 (MMC 4.41)

Boot configuration [PARTITION_CONFIG]: 0x48 , Boot from: ROM2 (Boot partition 1)

Boot Bus Config: 0x01 , width 4bit

H/W Reset Function [RST_N_FUNCTION]: 0x00, RST_n signal is temporarily disabled

Supported partition features [PARTITIONING_SUPPORT]: 0x03

Device supports partitioning features

Device can have enhanced technological features in partitions and user data area

Partition Settings [PARTITION_SETTING_COMPLETED]: 0x00

Backup saved: MAG4FA_63E00354_20180111_145208.extcsd
